1995 Sutphen 100' High Rail Aerial Platform - Quint

Sutphen TS-100 100 foot mid mount

Detroit Diesel 8V92TA, 450 horsepower, 8 cylinder, 736 displacement, 4.84 bore, 5.00 stroke

Rated ladder load capacity 800 pounds, 100 foot vertical reach, 88.5 horizontal reach

76,384 miles, 9494 engine hours, 455 pump hours, 608 ladder hours as of July 27, 2008

Hale 1500 GPM two stage pump with 300 gallon poly water tank

Onan diesel onboard generator with 6kW capacity, 120/240 Volt single phase, model number 6DJE

Four speed Allison World touchpad transmission with differential lock and On Spot chain system

Federal "Q" grill mounted siren, Code 3 electronic siren model number 3866, extended front bumper

Front and rear heat units, center mounted AC unit, two defroster fans

Enclosed cab seating for four, three Bostrom Tanker seats, additional SCBA holder on rear wall, air ride driver's seat, tilt/telescoping steering, anti lock brakes

Alcolite fiberglass ladders - 35 foot, 3 fly extension, 24 foot, 2 fly extension, (2) 16 foot roof ladders, (2) 10 foot folding attic ladders, Alcolite aluminum ladder - 14 foot combination, 6 foot fiberglass step ladder

Two shoreline powered 120 volt outlets in cab, one in exterior EMS compartment, four genset powered 120 volt outlets, one on each truck body side, one in platform basket and one in driver's side rear compartment

Two 2000 psi breathing air cylinders pre-piped to platform basket with Airminder system and two connection ports in basket, two mask storage compartments in basket

Sigtronic intercom system interfaced with mobile radio and cellular phone, one headset for each riding position in cab, one additional headset for pump panel/basket connection, fixed intercom between ladder turntable and platform basket

One electrically controlled master stream nozzle and one manual master stream nozzle in platform basket, electric nozzle has three functions, controllable at two locations - basket and turntable

One compartment mounted Hannay cord reel with 200 foot heavy duty 10/3 SJOW electric cable terminating in a four outlet receptacle box with handle, cord reel has electric rewind

One manual waterway wrench, one manual cab tilt wrench, one folding Zico wheel chock, one refill air line for breathing air tanks - 25 foot in length with bleeder valve

Original owners - currently in front line service, pump is tested annually (documentation available), ladders are independently tested annually (documentation available),

Serviced regularly.



Available Immediately !
Asking $245,000 Will consider offers!



Adirondack Fire Equipment
vjrusch@acmenet.net
1-800-635-4552
